Parameters:
Reflector : smooth
LED: W5050SQ3
LENS: ar-coated glass lens
Driver: output 3V 5A 12 groups
Range: 6500K - ANSI 866 meters,187.5KCD
3000K - ANSI 781 meters,152.5KCD
Battery : C8+ runs on 1pcs 18650 unprotected INR or IMR lithium battery
Diameter of head : 44.5mm
Length : 142mm
Diameter of body : 25.2mm
Weight : 145g
12 groups:
1.click the switch to turn the flashlight on/off,tap the switch to select mode
2.if flashlight is turned on,tap the switch 20 times quickly to enter into config mode.(On a visual interface,as long as you click on an option, it means that the option is selected. The flashlight has no visual interface. It flashes to represent an option, and "tap the switch in the flashing process" means to select the option.)
Option 1 (normal-flash 1 time + buzz-flash): tap the switch to enter into sub-option to select the mode group,If the user has no operation, the config mode will enter option 2.
-------------sub-option 1.1 (normal-flash 1 time) : tap the switch to select mode group 1 (0.1%, 1%, 10%, 35%, 100%, strobe, biking, battery-check)
-------------sub-option 1.2 (normal-flash 2 times) : tap the switch to select mode group 2 (0.1%, 1%, 10%, 35%, 100%)
-------------sub-option 1.3 (normal-flash 3 times) : tap the switch to select mode group 3 (100%, 35%, 10%, 1%, 0.1%)
-------------sub-option 1.4 (normal-flash 4 times) : tap the switch to select mode group 4 (1%, 20%, 100%, strobe, biking, battery-check, SOS)
-------------sub-option 1.5 (normal-flash 5 times) : tap the switch to select mode group 5 (1%, 20%, 100%)
-------------sub-option 1.6 (normal-flash 6 times) : tap the switch to select mode group 6 (100%, 20%, 1%)
-------------sub-option 1.7 (normal-flash 7 times) : tap the switch to select mode group 7 (0.1%, 1%, 10%, 50%, strobe, biking, battery-check, SOS)
-------------sub-option 1.8 (normal-flash 8 times) : tap the switch to select mode group 8(0.1%, 1%, 10%, 50%)
-------------sub-option 1.9 (normal-flash 9 times) : tap the switch to select mode group 9 (50%, 10%, 1%, 0.1%)
-------------sub-option 1.10 (normal-flash 10 times) : tap the switch to select mode group 10 (1%, 10%, 35%, 100%)
-------------sub-option 1.11 (normal-flash 11 times) : tap the switch to select mode group 11 (100%, 20%, strobe)
-------------sub-option 1.12 (normal-flash 12 times) : tap the switch to select mode group 12(100% only)
Option 2 (normal-flash 2 times + buzz-flash): tap the switch to active the mode memory or inactive it,If the user has no operation,flashlight will enter into the last mode.
battery-check instructions:
<2.95V 1 flash,
2.95-3.25V 2 flashes,
3.25-3.55V 3 flashes,
3.55-3.85V 4 flashes,
>3.85V 5 flashes
About battery
EVE 35V
Full Model Name: INR18650/35V
It is manufactured by EVE Energy Co., Ltd.,
|
Item
|
Specification
|
|
3.1TypicalDischarge Capacity
|
3500mAh
Charge: 0.68A,4.20V,CCCV 68mAcut-off Discharge: 0.68A, 2.50V DCcut-off
|
|
3.2 Min. DischargeCapacity
|
3400mAh
Charge: 0.68A,4.20V,CCCV 68mAcut-off Discharge: 0.68A, 2.50V DCcut-off
|
|
3.3TypicalVoltage
|
3.60V
|
|
3.4 StandardCharge
|
CCCV,0.68A,4.20±0.05V,68mAcut-off
|
|
3.5 RapidCharge
|
CCCV,1.5A,4.20±0.05V,68mAcut-off
|
|
3.6 StandardDischarge
|
DC, 0.68A, 2.50Vcut-off
|
|
3.7 Max.Discharge
|
Continuous
|
DC, 10.2A, 2.50V cut-off (Not for cyclelife)
|
|
Instantaneous
|
DC, 13A, 2.50Vcut-off
|
|
3.8 Charge/DischargeVoltageRange
|
4.20~2.50V
|
|
3.9 CellWeight
|
50.0gMax
|
|
3.10 CellDimension
|
Height: 65.00±0.15mm Diameter:18.35±0.10mm
|
|
3.11OperationTemperature(SurfaceTemperature)
|
Charge: 0 to 15°C
|
0.2C
|
|
Charge: 15 to 45°C
|
0.5C
|
|
|
Discharge: -20 to 60°C(Pack cut-off temperature70°C)
|
|
3.12 StorageTemperature(At ShippingSOC)
|
1year
3months
1month
|
0~25°C
0~45°C
0~60°C
|
Liitokala 35A
Brand: LiiitoKala
Model: Lii-35A
Battery Type: Li-Ion 18650
Rated Capacity: 3500mah(3300-3500mah)
Rated voltage: 3.7v
Weight: 47g ± 1g
Rechargeable battery: Yes
Rechargeable times: up to 500 times
Internal resistance: 38m
Limited charging voltage: 4.2v
Working Voltage: 2.75-4.2v
Size: 65.5mm x 18.5mm (diameter)
Molicel M35A
Full Model Name:INR-18650-M35A
It is manufactured byE-One Moli Energy Corp.
RATED SPECIFICATIONS
|
Items
|
Specifications
|
Remarks
|
|
1
|
Ratedcharge
|
Limiting 1.7A and constant 4.2V charge for 2.5h or 100mA at 23oC.
|
|
2
|
Rateddischarge
|
Constant 0.68A discharge until 2.5V at 23oC.
|
|
3
|
Ratedcapacity
|
3.35Ah(Minimum) 3.45Ah (Typical)
|
Rated discharge capacity after rated charge.
|
|
4
|
Nominalvoltage
|
3.6V
|
Mean voltage during rated discharge after ratedcharge.
|
|
5
|
Shippingvoltage
|
3.45V
|
Nominal approximate state of charge 30%.
|
|
6
|
Internalresistance
|
35m
|
Fresh cell measured by AC impedance at 1kHz
|
|
7
|
End of chargevoltage
|
4.20 0.05V
|
|
|
8
|
End of dischargevoltage
|
2.5V
|
Discharge voltage for determination of rated capacity.
|
|
9
|
Chargingtime
|
150min
|
Ratedcharge.
|
|
10
|
Maximum charging current
|
1.7A
|
|
|
Maximum discharging current
|
10A
|
Cycle life is reduced at high rates.
|
|
11
|
Operating temperature
|
Charging
|
0 ~ 60oC
|
|
|
Discharging
|
-40 ~ 60oC
|
|
|
12
|
Storage temperature for shippingcell
|
< 35oC
|
Recommended temperature less than 23oC forlongtermstorage.
|
